Wide Selection — available in a wide variety of body materials, linings and end connections. By utilizing such highly resistant linings as Saran, Polypropylene, Kynar, Tefzel, Glass, Rubber, etc., virtually any chemical service within the pressure/temperature limits of the valve can be handled safely and economically.

No Stem Leakage — since the diaphragm isolates the fluid stream there is no need for a packing gland — no atmospheric contamination, no leakage or waste, no expensive maintenance of stem, seats or stuffing box.

Bubble-Tight Shut Off — results when the downward thrust of the stem and compressor assembly molds the flexible diaphragm against the weir. The diaphragm will accommodate itself to rust, scale, slurry, or fibrous material.

Streamline Flow — with minimum pressure drop because of the absence of grooves, pockets or sharp changes in direction of flow.

Cost Saving — simple in-line maintenance. In less time than it takes to remove and replace a conventional valve, a new body diaphragm can be installed. Thus providing essentially a brand new valve at a tiny faction of the cost of a new or repaired conventional valve — all without removing the valve body from the line.

Flow Control — the automated diaphragm valve provides an excellent means of handling the changing flow requirements in most process installations. By the addition of a positioner to the actuator, even more precise control can be achieved, especially in the handling of slurries, or viscous and fibrous materials.

Body Materials — available in cast iron, ductile iron, carbon steel, stainless steel, Alloy-20, aluminum and bronze
